Product Summary

The EP3C80F780C8N is a high functionality, low power and low cost FPGA. Based on Taiwan Semiconductor Manufacturing Company (TSMC) low-power (LP) process technology, silicon optimizations and software features to minimize power consumption, the EP3C80F780C8N provides the ideal solution for your high-volume, low-power, and cost-sensitive applications.

Parametrics

EP3C80F484C8N absolute maximum ratings: (1)Supply voltage for internal logic: –0.5 to 1.8 V; (2)Supply voltage for output buffers: –0.5 to 3.9 V; (3)Supply (analog) voltage for PLL regulator: –0.5 to 3.75 V; (4)Supply (digital) voltage for PLL: –0.5 to 1.8 V; (5)DC input voltage: –0.5 to 3.95 V; (6)DC output current, per pin: –25 to 40 mA; (7)Electrostatic discharge voltage using the human body model: ±2000 V; (8)Electrostatic discharge voltage using the charged device model: ±500 V; (9)Storage temperature: –65 to 150 ℃.

Features

EP3C80F484C8N features: (1)Configuration security using advanced encryption standard (AES) with 256-bit volatile key; (2)Routing architecture optimized for design separation flow with the QuartusR II software: Design separation flow achieves both physical and functional isolation between design partitions; (3)Ability to disable external JTAG port; (4)Error Detection (ED) Cycle Indicator to core: Provides a pass or fail indicator at every ED cycle, Provides visibility over intentional or unintentional change of configuration random access memory (CRAM) bits.

Diagrams

EP3C80F484C8N block diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
EP3C80F484C8N
EP3C80F484C8N


IC CYCLONE III FPGA 80K 484 FBGA

Data Sheet

0-1: $133.80
Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
EP3C10E144C7
EP3C10E144C7


IC CYCLONE III FPGA 10K 144-EQFP

Data Sheet

0-1: $13.86
EP3C10E144C7N
EP3C10E144C7N


IC CYCLONE III FPGA 10K 144-EQFP

Data Sheet

0-1: $13.86
EP3C10E144C8
EP3C10E144C8


IC CYCLONE III FPGA 10K 144-EQFP

Data Sheet

0-1: $11.52
EP3C10E144C8N
EP3C10E144C8N


IC CYCLONE III FPGA 10K 144-EQFP

Data Sheet

0-1: $11.52
EP3C10E144I7
EP3C10E144I7


IC CYCLONE III FPGA 10K 144 EQFP

Data Sheet

0-120: $16.86
EP3C10E144I7N
EP3C10E144I7N


IC CYCLONE III FPGA 10K 144 EQFP

Data Sheet

0-1: $17.28
