Product Summary

The DA227TL is a Switching diode. The applications of the DA227TL include Ultra high speed switching.

Parametrics

DA227TL absolute maximum ratings: (1)Reverse voltage (repetitive peak), VRM: 80V; (2)Reverse voltage (DC), VR: 80V; (3)Peak reverse voltage (single), IFM: 300mA; (4)Rverage rectified forward current (single), IO: 100mA; (5)Surge current （t=1us), Isurge: 4A; (6)Power dissipation, Pd: 150mW; (7)Junction temperature, Tj: 150℃; (8)Storage temperature, Tstg: -55 to +150℃.

Features

DA227TL features: (1)Small mold type. (UMD4); (2) High reliability.

Diagrams

DA227TL block diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
DA227TL
DA227TL
ROHM Semiconductor
Diodes (General Purpose, Power, Switching) SWITCH 80V 100MA SOT-343
Data Sheet
0-1: $0.31
1-25: $0.25
25-100: $0.18
100-500: $0.11
