Product Summary

The H1081 is a 10/100BASE-TX single port transformer module.

Parametrics

H1081 absolute maximum ratings: (1)Turns Ratio: 1: √2 1:1; (2)Insertion Loss: -2.0(dB MAX); (3)Return Loss: -18(dB MIN); (4)Crosstalk: -45(dB MIN); (5)Hipot: 1500(Vrms MIN).

Features

H1081 features: (1)RoHS-5 peak reflow temperature rating 235℃; (2)RoHS-6 peak reflow temperature rating 245℃; (3)Meets IEEE 802.3 specification; (4)Designed for use with transceivers for AMD & Micrel.

Diagrams

H1081 block diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
H1081NL
H1081NL
Pulse
Transformers Audio & Signal SINGLE PORT
Data Sheet
0-1: $3.63
1-10: $3.26
10-100: $2.47
100-500: $2.03
H1081NLT
H1081NLT
Pulse
Transformers Audio & Signal XFMR (SGL 1:1.414)
Data Sheet
0-180: $2.47
180-300: $2.47
300-500: $2.22
500-1000: $2.15
H1081T
H1081T
Pulse
Transformers Audio & Signal XFMR (SGL 1:1.414)
Data Sheet
0-80: $6.75
80-100: $6.29
100-300: $6.29
300-500: $5.40
H1081
H1081
Pulse
Transformers Audio & Signal SINGLE PORT
Data Sheet
0-1: $7.20
1-10: $6.75
10-100: $6.29
100-500: $5.40
