Product Summary
The EP2C35F484C6N is an FPGA. The EP2C35F484C6N can support complex digital systems on a single chip at a cost that rivals that of ASICs. Unlike other FPGA vendors who compromise power consumption and performance for low-cost, the EP2C35F484C6N offers 60% higher performance and half the power consumption of competing 90-nm FPGAs. The low cost and optimized feature set of the EP2C35F484C6N makes the device ideal solutions for a wide array of automotive, consumer, communications, video processing, test and measurement, and other end-market solutions.
Parametrics
EP2C35F484C6N absolute maximum ratings: (1)VCCINT, Supply voltage With respect to ground: -0.5 to 1.8 V; (2)VCCIO, Output supply voltage: -0.5 to 4.6 V; (3)VCCA_PLL, PLL supply voltage: -0.5 to 1.8 V; (4)VIN, DC input voltage: -0.5 to 4.6 V; (5)IOUT, DC output current, per pin: -25 to 40 mA; (6)TSTG, Storage temperature No bias: -65 to 150℃; (7)TJ, Junction temperature BGA packages under bias: 125℃.
Features
EP2C35F484C6N features: (1)133-MHz PCI-X 1.0 specification compatibility; (2)High-speed external memory support, including DDR, DDR2, and SDR SDRAM, and QDRII SRAM supported by drop in Altera IP MegaCore functions for ease of use; (3)Three dedicated registers per I/O element (IOE): one input register, one output register, and one output-enable register; (4)Programmable bus-hold feature; (5)Programmable output drive strength feature; (6)Programmable delays from the pin to the IOE or logic array; (7)I/O bank grouping for unique VCCIO and/or VREF bank settings.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 EP2C35F484C6N |
|
IC CYCLONE II FPGA 33K 484FBGA |
Data Sheet |
|
|
||||||
| Image | Part No | Mfg | Description | |
Pricing (USD) |
Quantity | ||||||
 |
EP2C15AF256C6N |
|
IC CYCLONE II FPGA 15K 256-FBGA |
Data Sheet |
|
|
||||||
|
EP2C15AF256C7N |
|
IC CYCLONE II FPGA 15K 256-FBGA |
Data Sheet |
|
|
||||||
|
EP2C15AF256C8N |
|
IC CYCLONE II FPGA 15K 256-FBGA |
Data Sheet |
|
|
||||||
|
EP2C15AF256I8N |
|
IC CYCLONE II FPGA 15K 256-FBGA |
Data Sheet |
|
|
||||||
|
EP2C15AF484C6N |
|
IC CYCLONE II FPGA 15K 484-FBGA |
Data Sheet |
|
|
||||||
|
EP2C15AF484C7N |
|
IC CYCLONE II FPGA 15K 484-FBGA |
Data Sheet |
|
|
||||||
