EP2AGX125EF35I5N

EP2AGX125EF35I5N, Field Programmable Gate Array, BGA, -25 to 40 mA, 3.75 V, Altera Corporation

Rated 5 Rating 5 | reviews | Write a review

Price:: US $324.00~355.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 9 :	355.00 / Piece
9 ~ 81 :	339.00 / Piece
81 ~ 900 :	324.00 / Piece

PartNumber:: EP2AGX125EF35I5N

Brand:: Altera Corporation - ALTR | Pack: BGA | D/C: 12+

Availability:: Supply Ability: 7/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Anne's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-01-15

From Other Seller

Part Number:EP2AGX125EF35I5N
US $324.00 - 355.00
Quantity:

piece

Product Summary

The EP2AGX125EF35I5N is a Field Programmable Gate Array.

Parametrics

EP2AGX125EF35I5N absolute maximum ratings: (1)VCC, Supplies power to the core, periphery, I/O registers, PCI Express (PIPE) (PCIe) HIP block, and transceiver PCS: -0.5 to 1.35 V; (2)VCCCB, Supplies power for the configuration RAM bits: -0.5 to 1.8 V; (3)VCCBAT Battery back-up power supply for design security volatile key register: -0.5 to 3.75 V; (4)VCCPD, Supplies power to the I/O pre-drivers, differential input buffers, and MSEL circuitry: -0.5 to 3.75 V; (5)VCCIO, Supplies power to the I/O banks: -0.5 to 3.9 V; (6)VCCD_PLL, Supplies power to the digital portions of the PLL: -0.5 1.35 V; (7)VCCA_PLL, Supplies power to the analog portions of the PLL and device-wide power management circuitry: -0.5 to 3.75 V; (8)VI, DC input voltage -0.5 to 4.0 V; (9)IOUT, DC output current, per pin: -25 to 40 mA; (10)VCCA, Supplies power to the transceiver PMA regulator: 3.75 V; (11)VCCL_GXB, Supplies power to the transceiver PMA TX, PMA RX, and clocking: 1.21 V; (12)VCCH_GXB, Supplies power to the transceiver PMA output (TX) buffer: 1.8 V; (13)TJ, Operating junction temperature: -55 to 125℃; (14)TSTG, Storage temperature (no bias): -65 to 150℃.

Features

EP2AGX125EF35I5N features: (1)Input frequency from REFCLK input pins: 637.5 MHz; (2)Phase frequency detector (CMU PLL and receiver CDR): 325 MHz; (3)Absolute VMAX for a REFCLK pin: 1.6 V; (4)Operational VMAX for a REFCLK pin: 1.5 V; (5)Absolute VMIN for a REFCLK pin: -0.4V; (6)Rise/fall time: 0.2 UI; (7)Duty cycle: 55 %; (8)Peak-to-peak differential input voltage: 1600 mV; (9)Spread-spectrum modulating clock frequency PCIe: 33 kHz.
